Organometallics
Article
residue was dissolved in a minimal amount of warm toluene and the
solution filtered through Celite. The toluene was removed in vacuo to
afford 101 mg (68% yield) of a yellow solid, which was washed with
diethyl ether and dried in vacuo. Crystals suitable for X-ray diffraction
were grown by vapor diffusion of pentane into a saturated benzene
solution at 23 °C. 1H NMR: δ 78.3 (v br, 6 CH3), 41.2 (br s, 4 CH),
2.4(1) μB. UV−vis (toluene; λ, nm (ε, M−1 cm−1)): 378 (2720).
Repeated analyses consistently yielded low values for C, as has been
observed in other NHC systems.21 Anal. Calcd for C44H54CoN4: C,
75.73; H, 7.80; N, 8.03. Found: C, 74.51; H, 7.52; N, 7.93.
Notes
The authors declare no competing financial interest.
ACKNOWLEDGMENTS
■
This work was supported by startup funding from the
University of Texas at San Antonio and by a grant from the
Welch Foundation (AX-1772 to Z.J.T.). We thank Mr.
Jonathan Caranto for assistance with EPR measurements.
−5.00 (br s, 24 o-Me), −5.87 (s, 12 p-Me), −6.02 (s, 8 m-H). μeff
=
[Co(CH2SiMe3)2(IPr)]. A flask was charged with 188 mg (182
μmol) of [Co2Cl2(μ-Cl)2(IPr)2] and 25 mL of diethyl ether. The
resulting blue suspension was briefly stirred and then chilled to −30
°C. To the chilled suspension was added 1.0 mL (1.0 mmol) of 1.0 M
Me3SiCH2MgCl. The suspension quickly became yellow and was
allowed to react for 5 min with warming to ambient temperature. All
volatiles were then removed in vacuo, and the resulting yellow residue
was extracted into pentane and the extract filtered through glass filter
paper. Evaporation of the pentane afforded 203 mg (89% yield) of a
yellow solid. Crystals suitable for X-ray diffraction were grown by slow
REFERENCES
■
(1) Díez-Gonzal
3612−3676.
́
ez, S.; Marion, N.; Nolan, S. P. Chem. Rev. 2009, 109,
(2) Hu, X.; Meyer, K. J. Organomet. Chem. 2005, 690, 5474−5484.
(3) Tye, J. W.; Lee, J.; Wang, H.-W.; Mejia-Rodriguez, R.;
Reibenspies, J. H.; Hall, M. B.; Darensbourg, M. Y. Inorg. Chem.
2005, 44, 5550−5552.
(4) Capon, J.-F.; El Hassnaoui, S.; Gloaguen, F.; Schollhammer, P.;
Talarmin, J. Organometallics 2005, 24, 2020−2022.
(5) Morvan, D.; Capon, J.-F.; Gloaguen, F.; Le, G. A.; Marchivie, M.;
Michaud, F.; Schollhammer, P.; Talarmin, J.; Yaouanc, J.-J.; Pichon, R.;
Kervarec, N. Organometallics 2007, 26, 2042−2052.
(6) Hess, J. L.; Hsieh, C.-H.; Reibenspies, J. H.; Darensbourg, M. Y.
Inorg. Chem. 2011, 50, 8541−8552.
1
cooling of a saturated pentane solution at −30 °C. H NMR: δ 27.9
(br s, 4 CHMe2), 27.11 (s, 18 SiMe3), 12.94 (s, 12 CHMe2), −22.09 (s,
2 p-H), −26.05 (s, 4 m-H), −70.04 (s, 12 CHMe2), −101.85 (s, 2
CH). μeff = 5.1(1) μB. UV−vis (toluene; λ, nm (ε, M−1 cm−1)): 313
(3020). Anal. Calcd for C35H58CoN2Si2: C, 67.93; H, 9.45; N, 4.53.
Found: C, 67.33; H, 9.18; N, 4.54.
(7) Ingleson, M. J.; Layfield, R. A. Chem. Commun. 2012, 48, 3579−
3589.
Reaction of [Co(CH3)2(IMes)2] with CO To Form
[Co2(CO)6(IMes)2]. A ∼20 mM solution of [Co(CH3)2(IMes)2] in
benzene-d6 was transferred to an NMR tube that was sealed with a
septum. An excess of CO gas was introduced to the headspace of the
tube via a needle through the septum cap. The solution immediately
darkened, and NMR and IR spectra were recorded within 15 min. See
Figures S11 and S12 (SI) for spectra. Protracted standing of the
reaction solution at ambient temperature resulted in IR spectra
different from those obtained immediately after the introduction of
CO (Figure S12, SI). Subjection of the reaction mixture to vapor
diffusion of pentane afforded crystals of the cobaltate species
(IMes·H)[Co(CO)3(IMes)] after 2 weeks (Figure S13, SI). 1H
NMR for [Co2(CO)6(IMes)2] immediately after reaction: δ 6.76 (s, 8
m-H), 6.09 (s, 4 CH), 2.09 (s, 12 p-Me), 2.06 (s, 24 o-Me). IR
(C6D6 solution; cm−1): 2009 (νCO), 1963 (νCO), 1940 (νCO).
General Procedure for Catalytic Reactions Employing
[CoCl2(IMes)2]. In a representative procedure, a scintillation vial was
charged with 5.0 mg (6.8 μmol, 2 mol %) of [CoCl2(IMes)2] and 5
mL of THF. To the vial was added 339 μmol of the desired
electrophile. The solution was stirred briefly before 339 μmol of the
Grignard reagent was added in one portion. The reaction was stirred at
ambient temperature for 1 h, after which time it was quenched with 5
mL of 2 M aqueous oxalic acid. The organic layer was separated using
diethyl ether and an aliquot subjected to GC-MS analysis. All trials
were repeated multiple times, and the products were confirmed by
their MS signatures. Catalytic trials requiring low temperatures were
carried out in a similar fashion at −20 °C by use of a dry ice/ethylene
glycol bath. GC-MS analysis of control reactions carried out with both
coupling partners in the presence of IMes or IPr did not produce a
detectable amount of the coupled products or biphenyl.
(8) Silberstein, A. L.; Ramgren, S. D.; Garg, N. K. Org. Lett. 2012, 14,
3796−3799.
(9) Ghorai, S. K.; Jin, M.; Hatakeyama, T.; Nakamura, M. Org. Lett.
2012, 14, 1066−1069.
(10) Xiang, L.; Xiao, J.; Deng, L. Organometallics 2011, 30, 2018−
2025.
(11) Gao, H.-H.; Yan, C.-H.; Tao, X.-P.; Xia, Y.; Sun, H.-M.; Shen,
Q.; Zhang, Y. Organometallics 2010, 29, 4189−4192.
(12) Li, B.-J.; Xu, L.; Wu, Z.-H.; Guan, B.-T.; Sun, C.-L.; Wang, B.-
Q.; Shi, Z.-J. J. Am. Chem. Soc. 2009, 131, 14656−14657.
(13) Danopoulos, A. A.; Pugh, D.; Smith, H.; Saßmannshausen, J.
Chem. Eur. J. 2009, 15, 5491−5502.
(14) Gosmini, C.; Begouin, J. M.; Moncomble, A. Chem. Commun.
2008, 3221−3233.
(15) Cahiez, G.; Moyeux, A. Chem. Rev. 2010, 110, 1435−1462.
(16) Song, W.; Ackermann, L. Angew. Chem., Int. Ed. 2012, 51,
8251−8254.
(17) Gao, K.; Yoshikai, N. Chem. Commun. 2012, 48, 4305−4307.
(18) Gao, K.; Lee, P.-S.; Long, C.; Yoshikai, N. Org. Lett. 2012, 14,
4234−4237.
(19) Hatakeyama, T.; Hashimoto, S.; Ishizuka, K.; Nakamura, M. J.
Am. Chem. Soc. 2009, 131, 11949−11963.
(20) Someya, H.; Ohmiya, H.; Yorimitsu, H.; Oshima, K. Org. Lett.
2007, 9, 1565−1567.
(21) Przyojski, J. A.; Arman, H. D.; Tonzetich, Z. J. Organometallics
2012, 31, 3264−3271.
(22) Danopoulos, A. A.; Braunstein, P.; Stylianides, N.; Wesolek, M.
Organometallics 2011, 30, 6514−6517.
(23) Danopoulos, A. A.; Braunstein, P.; Wesolek, M.; Monakhov, K.
Y.; Rabu, P.; Robert, V. Organometallics 2012, 31, 4102−4105.
(24) Hashimoto, T.; Urban, S.; Hoshino, R.; Ohki, Y.; Tatsumi, K.;
Glorius, F. Organometallics 2012, 31, 4474−4479.
(25) Zhang, Q.; Xiang, L.; Deng, L. Organometallics 2012, 31, 4537−
4543.
ASSOCIATED CONTENT
■
S
* Supporting Information
Figures S1−S15, Table S1, and CIF files containing additional
structures, spectra, and crystallographic data. This material is
(26) Mo, Z.; Zhang, Q.; Deng, L. Organometallics 2012, 31, 6518−
6521.
(27) Macomber, D. W.; Rogers, R. D. Organometallics 1985, 4,
1485−1487.
(28) Delgado, S.; Moreno, C.; Macazaga, M. J. Polyhedron 1991, 10,
725−729.
AUTHOR INFORMATION
■
Corresponding Author
(29) Simms, R. W.; Drewitt, M. J.; Baird, M. C. Organometallics 2002,
21, 2958−2963.
I
dx.doi.org/10.1021/om3010756 | Organometallics XXXX, XXX, XXX−XXX
