(m/z): 270.66 (100, [M + H]+). Elemental analysis calc. (%)
for C14H14N4O2 (270.287): C, 62.21; H, 5.22; N, 20.73; found
C, 62.40; H, 5.38; N, 20.62.
NMR data of 3-methylxanthine (3MX) aggregates
See Table 3, Table 4 and Fig. 4.
Method B39. Compound 136 (0.900 g, 3.72 mmol) was
dissolved in water (12 mL) and 1 M sodium hydroxide
(4.5 mL, 1.2 equiv.) under sonication and warmed to effect
dissolution. After the addition of methyl iodide (0.527 g,
3.72 mmol, 1 equiv.), the reaction mixture was shaken for
2 h using a peptide shaker. The obtained heterogeneous
solution was diluted with water (500 mL) and extracted with
EtOAc (5 ꢂ 100 mL). The organic layer was dried (Na2SO4),
filtered, evaporated in vacuo and co-evaporated with MeCN
(3 ꢂ 100 mL). The crude product was purified by column
chromatography using the solvent system 5–20 v/v% EtOAc
in CH2Cl2 to give compounds 2 (0.300 g, 31.5%) and 3
(0.148 g, 14.7%), along with unreacted starting material 1
(0.483 g, 53.8%).
Acknowledgements
This study was supported by grants OTKA NK 73672, NK
´
68578, CK 77515, COST Action MP0802, TAMOP 4.2.1.B 09/
1/KONV, University of Szeged, HPC-Europa2, Free
University of Amsterdam and the SARA Supercomputing
Center. We also thank the Netherlands Organization for
Scientific Research (NWO-CW and NWO-NCF) and the
National Research School Combination-Catalysis (NRSC-C)
for financial support, and Mr. Istvan Mandity for his
´ ´
assistance with the H-Cubes flow reactor.
Notes and references
1 J. W. Steed and J. L. Atwood, Supramolecular Chemistry,
John Wiley and Sons, Chichester, 2000.
2 S. Neidle and S. Balasubramanian, Quadruplex Nucleic Acids,
The Royal Society of Chemistry, Cambridge, 2006.
3 S. Neidle, FEBS J., 2009, 277, 1118–1125.
4 J. T. Davis and G. P. Spada, Chem. Soc. Rev., 2007, 36, 296–313.
5 S. Lena, S. Masiero, S. Pieraccini and G. P. Spada, Chem.–Eur. J.,
2009, 15, 7792–7806.
6 M. Franceschin, Eur. J. Org. Chem., 2009, 2225–2238.
7 J. Gros, F. Rosu, S. Amrane, A. De Cian, V. Gabelica, L. Lacroix
and J.-L. Mergny, Nucleic Acids Res., 2007, 35, 3064–3075.
8 S. Mezzache, S. Alves, J. P. Paumard, C. Pepe and J. C. Tabet,
Rapid Commun. Mass Spectrom., 2007, 21, 1075–1082.
9 P. K. Patel, A. S. R. Koti and R. V. Hosur, Nucleic Acids Res.,
1999, 27, 3836–3843.
3-Methylxanthine (3MX)27,30
Method A. Compound 2 (500 mg, 1.95 mmol) was dissolved
in 1,4-dioxane or AcOH (50 mL) and Pearlman’s catalyst
(0.96 g) was added in a batch reactor. The reactor was filled
with H2 (75–100 bar) and the reaction mixture heated at 90 1C
with stirring for 24 h. The reaction mixture was filtered, the
filtrate evaporated in vacuo and co-evaporated with MeCN
(3ꢂ). The crude product was purified by column chromato-
graphy using the solvent system 20 v/v% MeOH in CH2Cl2 to
give the product (150 mg, 46.3%). 3MX was crystallized from
water. Mp. > 300 1C. ESI-MS (m/z): 167 ([M + H]+).
Elemental analysis calc. (%) for C6H6N4O2 (166.137): C,
43.38; H, 3.64; N, 33.72; found C, 43.51; H, 3.50; N, 33.93.
For detailed NMR data, see Table 3, Table 4 and Fig. 4.
10 B. C. Pan, Y. Xiong, K. Shi, J. P. Deng and M. Sundaralingam,
Structure, 2003, 11, 815–823.
11 T. van der Wijst, B. Lippert, M. Swart, C. Fonseca Guerra and
F. M. Bickelhaupt, JBIC, J. Biol. Inorg. Chem., 2010, 15, 387–397.
12 C. Fonseca Guerra, T. van der Wijst, J. Poater, M. Swart and
F. M. Bickelhaupt, Theor. Chem. Acc., 2010, 125, 245–252.
13 F. W. Smith and J. Feigon, Biochemistry, 1993, 32, 8682–8692.
14 F. W. Smith, P. Schultze and J. Feigon, Structure, 1995, 3,
997–1008.
15 B. C. Pan, K. Shi and M. Sundaralingam, J. Mol. Biol., 2006, 363,
451–459.
16 F. C. Meng and X. Zhao, THEOCHEM, 2008, 869, 94–97.
17 C. J. Cheong and P. B. Moore, Biochemistry, 1992, 31, 8406–8414.
18 E. L. Zins, S. Rochut and C. Pepe, J. Mass Spectrom., 2009, 44,
813–820.
Method B. Compound 2 (25 mg, 0.0975 mmol) was
dissolved in 15 v/v% AcOH in EtOAc (25 mL). A cartridge
for the H-Cubes reactor was loaded with Pearlman’s catalyst
(20 mg). The catalyst was activated for 15 min in a H2
atmosphere (100 bar). Debenzylation in the H-Cubes flow
reactor was conducted at 90 1C, a 100 bar H2 atmosphere and
at a 1 mL minꢁ1 flow rate for 25 min. The catalyst could be
reused several times. The solution was evaporated and the
product (3MX) recrystallized from water (14.5 mg, 90%). The
19 E. L. Zins, S. Rochut and C. Pepe, J. Mass Spectrom., 2009, 44,
40–49.
20 P. K. Patel and R. V. Hosur, Nucleic Acids Res., 1999, 27,
2457–2464.
1
analytical data (Rf, H, 13C NMR, MS) of this sample were
identical with that obtained using Method A.
21 P. K. Patel, N. S. Bhavesh and R. V. Hosur, Biochem. Biophys.
Res. Commun., 2000, 270, 967–971.
22 J. Sponer and N. Spackova, Methods, 2007, 43, 278–290.
´
23 J. D. Gu and J. Leszczynski, Chem. Phys. Lett., 2002, 351,
403–409.
Nano-ESI-MS data of 3-methylxanthine (3MX) aggregates
High resolution mass spectrometry experiments were
performed on a Waters MALDI Q-TOF Premier instrument
equipped with a nano-ESI ion source containing a gold-coated
borosilicate capillary tip. Voltages: capillary: 1.4–1.8 kV,
sampling cone: 28 V, extraction cone: 4.9 V; source
temperature: 95 1C; cone gas 20 l hꢁ1; nanoflow gas: 0. The
sample was prepared in the following way: a saturated
aqueous solution of 3-MX, containing 100 mM NH4HCO3
(pH 8) and methanol saturated with NH4HCO3 were mixed in
a 1 : 99 ratio, and the resulting dilute solution was used directly
for experiments.
24 E. Kulikowska, B. Kierdaszuk and D. Shugar, Acta Biochim.
Polon., 2004, 51, 493–531.
25 J. Song, K. U. Park, H. D. Park, Y. Yoon and J. Q. Kim, Clin.
Chem., 2004, 50, 2176–2179.
genome.jp/kegg/pathway/map/map00232.html).
27 B. S. Lindsay, A. M. P. Almeida, C. J. Smith, R. G. S. Berlinck,
R. M. da Rocha and C. M. Ireland, J. Nat. Prod., 1999, 62,
1573–1575.
28 G. A. Soukup, G. A. M. Emilsson and R. R. Breaker, J. Mol. Biol.,
2000, 298, 623–632.
29 S. W. Lee, L. Zhao, A. Pardi and T. B. Xia, Biochemistry, 2010, 49,
2943–2951.
c
This journal is The Royal Society of Chemistry and the Centre National de la Recherche Scientifique 2011
New J. Chem., 2011, 35, 476–482 481
