4
Moderate loss of enantiomeric purity was observed for para
and ortho-triflate derivatives, respectively 4b and 4c (Entries 2
and 3).
nitrile followed by ring closure, and a concerted [2 + 3]
cycloaddition.18 In our case both mechanisms do not necessarily
involve the chiral center.
The method proved to be very efficient in the synthesis of a
single tetrazole’s enantiomer structurally related to some active
pharmaceutical ingredients, such as: Ibuprofen 4d (Table 2, entry
4), Ketoprofen 4f (Entry 6) and Flurbiprofen 4g (Entry 7). A
comparable result was achieved for the meta-alkyl compound 4e.
To further examine the range of applicability of this reaction,
the 4-nitrophenyl derivative 4h was synthesized. The common
method used for the preparation of the amides 2a-g, via
activation by EDC/HOBt gave a complete racemization when
applied to synthesis of intermediate 2h. The mentioned amide 2h
was differently obtained with 92% e.e. by activation with CDI
and subsequent bubbling with gaseous ammonia (Table 2, entry
8). A loss of optical purity occurred in the dehydration step to
obtain nitrile derivatives 3h, (70%, Table 2, Entry 8). We then
applied our standard protocol with Me3SnN3 but tetrazole was
obtained as a racemic mixture. All attempts done for the
synthesis of chiral tetrazole 4h, unfortunately failed.
In order to assess the (2R)-2-(4-nitrophenyl)propanenitrile (3h)
stability without any source of azide, the compound was
subjected to a set of different conditions mimicking the standard
ones or testing mechanism hypotheses. Mild anhydrous acidic
conditions (cat. AcOH), mild anhydrous basic (an. sodium
bicarbonate), mild aqueous basic (sodium bicarbonate) and
simple heating in toluene at 130°C, all led to optical purity loss.
Negligible loss of enantiomeric purity was observed for the
nitrile derivatives 3a-g by heating at 130°C for 30 minutes.
All these tests taken together point toward tautomeric
mechanisms assisting the proton abstraction that causes
racemization in the 4-nitro derivative. Furthermore, the absence
of a solvent capable of proton coordination indicates that
intermolecular coordination between reacting nitrile molecules
may play a significant role in the supposed mechanism.
Differently from the two-step mechanism, which is generally
reported for azide ion in polar solvent, the concerted one is
described for covalent species such as alkyl azides. In our
hypothesis a greater degree of covalency in the nitrogen-metal
bond of the stannylazide as compared to sodium azide,19
presumably drives the reaction towards a 1,3-dipolar concerted
cyclization, as demonstrated by the stability of the isolated
intermediates 5f,h and the use of an apolar solvent like toluene.
In summary, we have demonstrated an exceedingly simple
protocol for the transformation of a wide variety of chiral
phenylacetonitrile into the corresponding 1H-tetrazoles; the
method has been successfully applied to an easily racemizable
alpha amino acid. By using Me3SnN3 we obtained a good to high
retention of configuration in high yields. The use of
trimethylstannyl azide under neutral condition prevents the
formation of toxic and explosive HN3. All the reactions were
carried out in a safe microwave reactor environment improving
time reaction, yield and considerably the optical purity in
comparison with the conventional thermal methods. Further
investigation is currently in progress in order to explore the
application to other chiral nitriles.
Acknowledgments
We thank Lucio De Simone for Chiral HPLC support.
References Note
1. (a) Kidd, B.L.; Urban, L.A. Br J Anaesth 2011, 87, 3-11; (b) Baron, R.;
Binder, A.; Wasner, G. Lancet Neurol 2010, 9, 807–819.
2. (a) Schaffer, D.; Florin, T.; Eagle, C.; Marschner, I.; Singh, G.; Grobler,
M.; Fenn, C.; Schou, M.; Curnow, K. M. Med J Aust 2006, 185, 501–506.
(b) Devulder, J.; Jacobs, A.; Richarz, U.; Wiggett, H. Br J Anaesth 2009,
103, 576–585.
3. (a) White, F. A.; Jung, H.; Miller, R. J. Proc Natl Acad Sci USA 2007, 104,
20151–20158. (b) Cunha, M.; Barsante, M. M.; Guerrero, A. T.; Verri Jr,
W.A.; Ferreira, S. H.; Coelho, F. M.; Bertini, R.; Di Giacinto, C.;
Allegretti, M.; Cunha, F. Q.; Teixeira, M.M. Br J Pharmacol 2008, 154,
460–470.
Tin-tetrazole adducts 5f,h were isolated directly from the
reaction medium: after 1.5 hours of microwave heating, the
mixture was cooled to room temperature and concentrated
without any workup and the products crystallized.15,16 Subsequent
acidic hydrolysis of 5h,f yielded the corresponding tetrazoles,
respectively 4f and 4h.
Continuing the investigations in the field of the carboxylic acid
replacement, the method has been successfully applied in the
synthesis of the tetrazole derivative of (R)-N-Cbz-phenylglycine.
Starting from chiral α-amino nitrile 6, obtained with an e.e. of
86% (Scheme 3), tetrazole 7 was synthesized obtaining a good
yield (79%) and a good enantiomeric purity (e.e. 80%). To the
best of our knowledge, derivative 7 has never been obtained with
an e.e. higher than 39%.17
4. (a) Ting, E.; Guerrero, A.T.; Cunha, T.M.; Verri Jr, W.A.; Taylor, S.M.;
Woodruff, T.M.; Cunha, F. Q.; Ferreira, S.H. Br J Pharmacol 2008, 153,
1043–1053. (b) Griffin, R.S.; Costigan, M.; Brenner, G.J.; Ma, C.H.;
Scholz, J.; Moss, A.; Allchorne, A.J.; Stahl, G.L. ; Woolf, C.J. J Neurosci
2007, 27, 8699–8708.
5. Gerard, C.; Gerard, N.P. Annu Rev Immunol 1994, 12, 775–808.
6. (a) Zwirner, J.; Fayyazi, A.; Gotze, O. Mol Immunol 1999, 36, 877–884.
(b) Jang, J. H.; Liang, D.; Kido, K.; Sun, Y.; Clark, D.J.; Brennan, T.J. J
Neuroinflammation 2011, 8, 80–97. (b) Jang, J.H.; Clark, J. D.; Li, X.;
Yorek, M.S.; Usachev, Y. M.; Brennan, T.J. Pain 2010, 148, 343–352.
7. (a) Himo, F.; Demko, Z.P.; Noodleman, L.; Sharpless, K.B. J. Am. Chem.
Soc. 2002, 124, 12210 and references cited therein.
N
H
N
H
N
N
N
N
Cbz
N
H
Cbz
Me3SnN3
8. Nicholas A. Meanwell J. Med. Chem. 2011, 54(8), 2529–2591.
9. Gutmann, B.; Roduit, J.P.; Roberge, D.; Kappe, C.O. Angew. Chem. Int.
Ed. 2010, 49, 7101–7105.
Toluene
MW, 130°C, 1h
10. (a) Carlier, P.R.; Taylor, P.; Venkateshwarlu, M.G.; Premalatha, G.;
Rajanna, A.; Saiprakash, K.C. Synth. Commun. 2009, 39, 4479–4485; (c)
Demko, Z.P.; Sharpless, K.B. J. Org. Chem. 2001, 66, 7945–7950; (d)
Amantini, D.; Fringuelli, F.; Pizzo, F.; Vaccaro, L. J. Org. Chem. 2001, 66,
6734; (e) Corriu, R.J.; Perez, R.; Reye, C. Tetrahedron 1983, 39, 999–
1009; (f) Witteberger, S.J.; Donner, B.G. J. Org. Chem. 1993, 58, 4139–
4141; (g) Breitonmoser, R.A.; Heimgartner, H. Helv. Chim. Acta 2002, 85,
885–912.
6
e.e. 86%
7
e.e. 80%, yield 79%
Scheme 3. Tetrazole analogous of (R)-N-Cbz-phenylglycine.
As described by Sharpless and coworkers in a relevant
computational study, two plausible mechanisms can be involved
at the same time in the the addition of the azide ion to the nitrile
leading to the tetrazole. The two considered are: a two-step
mechanism, wherein the azide first nucleophilically attacks the
11. Bräse, S.; Gil, C.; Knepper, K.; Zimmermann V. Angew. Chem. Int. Ed.
2005, 44, 5188–5240.
