Organic Process Research & Development
ARTICLE
scrubber containing 3 N NaOH were added the crude nitrile 6
(56 wt %, 10.96 kg, 16.8 mol), ZnO (137 g, 1.68 mol), THF
(6.2 L), and water (31 L). Sodium azide (1.20 kg, 18.5 mol)
[CAUTION: sodium azide is extremely toxic and may generate
hydrazoic acid in the presence of acid. Hydrazoic acid is shock-
sensitive, volatile, and toxic (see ref 16 for further details). Ensure
that all aqueous solutions of sodium azide are kept above pH 7,
wash all equipment with copious aqueous base post-use, and
ensure all azide-containing waste is collected separately, kept
basic, and disposed of separately] was dissolved in water (3.1 L)
and added via an addition funnel to the reaction mixture over
20 min. The mixture was then heated to 78 °C for 15 h, cooled to
ambient temperature, and transferred to an extractor charged
with saturated aqueous NaHCO3 (16 L), brine (16 L), and
2-MeTHF (31 L). The organic layer was separated and assayed
by HPLC (6.88 kg, 100% assay yield). The 25 wt % crude
solution was used directly in the next step. 1H NMR (500 MHz,
DMSO-d6) δ 7.60 (dd, J = 8.8, 6.4 Hz, 1 H), 7.23 (dd, J = 11.1, 2.8
Hz, 1 H), 6.77 (td, J = 8.5, 2.7 Hz, 1 H), 6.54 (s, 1 H), 4.79 (s,
1 H), 4.05 (s, 1 H), 3.53À3.47 (m, 2 H), 2.01À1.95 (m, 2 H),
1.77À1.71 (m, 2 H). 13C NMR (126 MHz, DMSO-d6) δ 166.7,
162.2 (d, JCF = 244 Hz), 156.5, 154.2 (d, JCF = 11 Hz), 133.7
(m, 2 H), 6.77 (td, J = 8.5, 2.7 Hz, 1 H), 5.83 (s, 2 H), 4.82À4.78
(m, 1 H), 3.59À3.53 (m, 2 H), 2.03À1.97 (m, 2 H), 1.78À1.71
(m, 2 H). 13C NMR and HRMS data obtained are in complete
accord with literature precedent.5
’ AUTHOR INFORMATION
Corresponding Author
*E-mail: sarah_dolman@merck.com.
’ ACKNOWLEDGMENT
We thank Claude Briand, Richard Desmangles, and Wayne
Mullett for analytical support. Also, we would like to express our
appreciation to Theintu Lam for helpful safety discussions.
’ REFERENCES
(1) Ntambi, J. M.; Miyazaki, M. Prog. Lipid Res. 2004, 43, 91–104.
(2) (a) Jiang, G.; Li, Z.; Liu, F.; Ellsworth, K.; Dallas-Yang, Q.; Wu,
M.; Ronan, J.; Esau, C.; Murphy, C.; Szalkowski, D.; Bergeron, R.;
Doebber, T.; Zhang, B. B. J. Clin. Invest. 2005, 115, 1030–1038. (b)
Miyazaki, M.; Flowers, M. T.; Sampath, H.; Chu, K.; Otzelberger, C.;
Liu, X.; Ntambi, J. M. Cell Metab. 2007, 6, 484–496.
(d, JCF = 10 Hz), 109.0 (d, JCF = 23 Hz), 107.0, 103.6 (d, JCF
=
(3) (a) Li, C. S.; Belair, L.; Guay, J.; Murgasova, R.; Sturkenboom,
W.; Ramtohul, Y. K.; Zhang, L.; Huang, Z. Bioorg. Med. Chem. Lett. 2009,
19, 5214–5217. (b) Leger, S.; Black, W. C.; Deschenes, D.; Dolman, S.;
Falgueyret, J.-P.; Gagnon, M.; Guiral, S.; Huang, Z.; Guay, J.; Leblanc, Y.;
Li, C.-S.; Masse, F.; Oballa, R.; Zhang, L. Bioorg. Med. Chem. Lett. 2010,
20, 499–502. (c) Ramtohul, Y. K.; Black, C.; Chan, C.-C.; Crane, S.;
Guay, J.; Guiral, S.; Huang, Z.; Oballa, R.; Xu, L.-J.; Zhang, L.; Li, C. S.
Bioorg. Med. Chem. Lett. 2010, 20, 1593–1597. (d) Issandou, M.;
Bouillot, A.; Brusq, J.-M.; Forest, M.-C.; Grillot, D.; Guillard, R.; Martin,
S.; Michiels, C.; Sulpice, T.; Daugan, A. Eur. J. Pharmacol. 2009,
618, 28–36. (e) Koltun, D. O.; Zilbershtein, T. M.; Migulin, V. A.;
Vasilevich, N. I.; Parkhill, E. Q.; Glushkov, A. I.; McGregor, M. J.; Brunn,
S. A.; Chu, N.; Hao, J.; Mollova, N.; Leung, K.; Chisholm, J. W.;
Zablocki, J. Bioorg. Med. Chem. Lett. 2009, 19, 4070–4074.
(4) (a) Attie, A. D.; Krauss, R. M.; Gray-Keller, M. P.; Brownlie, A.;
Miyazaki, M.; Kastelein, J. J.; Lusis, A. J.; Stalenhoef, A. F. H.; Stoehr,
J. P.; Hayden, M. R.; Ntambi, J. M. J. Lipid Res. 2002, 43, 1899–1907. (b)
Hulver, M. W.; Berggren, J. R.; Carper, M. J.; Miyazaki, M.; Ntambi,
J. M.; Hoffman, E. P.; Thyfault, J. P.; Stevens, R.; Dohm, G. L.; Houmard,
J. A.; Muoio, D. M. Cell Metab. 2005, 2, 251–261.
(5) Oballa, R. M.; Belair, L.; Black, W. C.; Bleasby, K; Chan, C. C.;
Desroches, C.; Du, X.; Gordon, R.; Guay, J.; Guiral, S.; Hafey, M. J.;
Hamelin, E.; Huang, Z.; Kennedy, B.; Lachance, N.; Landry, F.; Li, C. S.;
Mancini, J.; Normandin, D.; Pocai, A.; Powell, D. A.; Ramtohul, Y. K.;
Skorey, K.; Sørensen, D.; Sturkenboom, W.; Styhler, A.; Waddleton,
D. M.; Wang, H.; Wong, S.; Xu, L.; Zhang, L. J. Med. Chem. 2011, 54
(14), 5082–5096.
(6) (a) Soellner, M. B.; Rawls, K. A.; Grundner, C.; Alber, T.; Allman,
J. A. J. Am. Chem. Soc. 2007, 129, 9613–9615. (b) Rawls, K. A.; Grundner,
C.; Ellman, J. A. Org. Biomol. Chem. 2010, 8, 4066–4070. (c) Ueda, M.;
Ikeda, U.; Sato, A.; Ito, U.; Kakiuchi, M.; Shono, H.; Miyoshi, T.; Naito, T.;
Miyata, O. Tetrahedron 2011, 67, 4612–4615.
26 Hz), 97.1, 72.8, 43.7, 28.8.
(5-{3-[4-(2-Bromo-5-fluoro-phenoxy)-piperidin-1-yl]-iso-
xazol-5-yl}-tetrazol-2-yl)-acetic Acid tert-Butyl Ester (23). To
the crude solution of tetrazole 7 (25 wt %, 22 kg, 13.4 mol) was
added Et3N (3.3 L, 23.5 mol), and the mixture was heated to
55 °C. tert-Butylbromoacetate (3.0 L, 20.5 mol) was added over
20 min, and the internal temperature rose to 63 °C over the
course of the addition. The mixture was aged for 2 h 30 min at
58 °C and then cooled to 35 °C. It was transferred to an extractor
charged with aqueous HCl (1 N, 30 L). The layers were sepa-
rated, and the organic layer was washed with a mixture of water
and brine (15 L each) and assayed by HPLC (5.03 kg, 71% assay
yield and 1.25 kg of the desired 1-regioisomer). The solution was
filtered through a 1.0 μm inline filter, concentrated under
reduced pressure, flushed with heptane (20 L), and concentrated
to give a thick beige slurry (47 wt %). MTBE (25 L) and heptane
(5.8 L) were added to the slurry, and the resultant suspension
was warmed to 47 °C. After ageing for 16 h, the slurry was cooled
to 39 °C and the precipitate was recovered by filtration, rinsing
with a 3:1 mixture of MTBE/heptane (2.0 L). A light beige solid
was obtained (3.52 kg, 20:1 regioisomers, 70% isolated yield). 1H
NMR (500 MHz, DMSO-d6) δ 7.60 (dd, J = 8.8, 6.3 Hz, 1 H),
7.24 (d, J = 14.8 Hz, 2 H), 6.78 (td, J = 8.5, 2.8 Hz, 1 H), 5.85 (s,
2 H), 4.83À4.79 (m, 1 H), 4.03 (s, 1 H), 3.59À3.52 (m, 2 H),
2.03À1.97 (m, 2 H); 1.79À1.73 (m, 2 H); 1.43 (s, 9 H).13C
NMR (126 MHz, DMSO-d6) δ 166.7, 164.7, 162.3 (d, JCF = 245
Hz), 157.2, 155.3, 154.3 (d, JCF = 10 Hz), 133.7 (d, JCF = 10 Hz),
109.0 (d, JCF = 23 Hz), 107.0 (d, JCF = 2.5 Hz), 103.6 (d, JCF = 26
Hz), 97.0, 83.3, 72.9, 54.3, 43.7, 28.9, 27.5.
(7) Ouellet, S. G.; Bernardi, A.; Angelaud, R.; O’Shea, Paul. D.
Tetrahedron Lett. 2009, 50, 3776–3779.
(5-{3-[4-(2-Bromo-5-fluoro-phenoxy)-piperidin-1-yl]-iso-
xazol-5-yl}-tetrazol-2-yl)-acetic Acid (MK-8245). A suspen-
sion of tert-butyl ester 23 in formic acid (17 L) was heated to
95 °C for 2 h. The solution was cooled to 77 °C, and 80 g of seed
was added. The suspension was aged for 1 h, and water (6.5 L)
was added over 1 h. It was allowed to cool to 40 °C, aged for 14 h,
and then filtered. The cake was washed with water (17 L) and
dried in a vacuum oven at 70 °C (2.87 kg, 94% isolated yield,
98.1% pure as measured by HPLC at 210 nm). 1H NMR (500
MHz, DMSO-d6) δ 7.60 (dd, J = 8.8, 6.3 Hz, 1 H), 7.25À7.19
(8) (a) Berrier, J. V.; Umarvadia, A. S.; Rohm and Haas Company;
Improved synthesis of haloformimine compounds. Eur. Pat. Appl.
979814, Feb 16, 2000. (b) Rohloff, J. C.; Rubinsun, J., III; Gardner,
J. O. Tetrahedron Lett. 1992, 33, 3113–3116.
(9) Initial investigations using an inorganic base (KHCO3) showed
that some piperidine 3 was tied up as the HBr salt and thus reduced
conversion. Thus we set out to explore organic base additives
(dicyclohexylamine, 2,6-lutidine, piperidine, tetramethylpiperidine) to
free up piperidine 3 to react with oxime 4. In particular, it was noted the
1079
dx.doi.org/10.1021/op200186d |Org. Process Res. Dev. 2011, 15, 1073–1080
